24''x36'' Class 100 Tacky Floor Mat Sticky Mats Use In Cleanroom For Electronics Factory

Brand Name : QS

Model Number : 24''x36''

Certification : ISO9001,ISO14001

Place of Origin : China

MOQ : 50 PADS

Price : Negotiable

Packaging Details : 30 layers/set ,10 sets/box ,50 box/ctn

Size : 24'x36' tacky mats

Color : Sticky mats blue

Class : 100 cleanroom

Model : QS-ncd01

Package : 10pcs/box,5boxes/ctn

Application : Remove dust,Environmental protection

Contact Now

24x36 Class 100 Tacky Floor Mat Sticky Mats Use In Cleanroom For Electronics Factory

1.Production description of sticky mats

Tacky mats used in cleanroom for electronics factory

Item Name	Cleanroom Tacky Mat
Adhesive Thickness	7-8μm
Layers	30 layers
Film Material	LDPE
Adhesive Material	Water-based acrylic
Film Thicknes	35μm,40μm,45μm,50μm
Tensile Strength	≥1.2kg/cm
Color	Black, Blue, Gray, Transparent,White
Size	24''x36''

2.Technical Data of cleanroom mats

NO.	inspection items	test standard	inspection result
1	longitudinal tensile strength (MPA)	≥10	20
2	transverse tensile strength (MPA)	≥8	17
3	longitudinal elongation at break (%)	≥150	210
4	horizontal elongation at break (%)	≥200	255
5	State of glue		Light evenly
6	thickness	Plus or minus 0.005	0.035MM
7	Early viscous force (G/IN2)	LOOPTACK	500
8	180 degrees peel strength (SS. G / 25 mm)	GB2792-81	380
9	The viscosity (MIN)	GB4851-98	1440
10	Resistance to high temperature and high humidity test	Q/DT1-2004	80 degrees
11	Heat resistant experiment	Q/DT1-2004
12	Aging performance	Q/DT1-2004	8 months

3. Application of dust mats

Cleanroom protection

Factory protection

Environmental protection

Electronics factory

24''x36'' Class 100 Tacky Floor Mat Sticky Mats Use In Cleanroom For Electronics Factory
